Heating Capacity (KW)

                        22.0

                        Refrigerant

                        R410a

                        Compressor

                        Copeland

                        Rated Input Power (KW)

                        4.60

                        Charge（kg）

                        3.5

                        Condenser

                        Titanium Tube Heat-Exchanger

                        Rated Input Current (A)

                        9.5

                        Heating

                        Cycle

                        Evaporator

                        Aluminum Finned Evaporator

                        COP（W/W）

                        4.78

                        Water Flow (L/H)

                        380

                        Water Flow (L/H)

                        2-φ7

                        Power Supply (KW)

                        380V/3N/50Hz

                        Power Supply (KW)

                        4000

                        Throttle Device Type

                        EEV

                        Max Input Power (KW)

                        5.6

                        Inlet Water Connection（mm）

                        PVC Tube DN50

                        Fan Position

                        Vertical

                        Max Input Current (A)

                        12.5

                        Outlet Water Connection（mm）

                        PVC Tube DN50

                        Water Rated Pressure（MPa）

                        0.55

                        Noise（dB)

                        ≤60

                        Power Cord

                        3x6.0mm2+2x4.0mm2

                        Water Pressure Loss（kPa）

                        60

                        Working Temperature（℃）

                        -10～43

                        Water Pump：Stroke-Flow

                        10m-6m3/h

                        Size（mm）

                        717x717x950

                        Rated Outlet Water Temperature（℃）

                        28

                        Operation

                        Wire Controller

                        Unit Weight（kg）

                        105

                        Max Outlet Water Temperature（℃）

                        43
